Measured Building Surveys (MBS)

At SurveyWorx, delivering accurate & reliable Geospatial Data is the foundation of what we do.

Drift Bridge House

Measure, Map, Model

Detailed Measured Building Surveys accurately map & define key structural elements, delivering external & internal layouts of a Building/Structure.

At SurveyWorx we deliver detailed Measured Building Surveys (MBS) which provide accurate, reliable data to identify key structural elements, external & internal layouts/profiles of buildings, from single-storey houses, residential properties, multi-storey office buildings, to listed heritage buildings.

  • Floor Plans, Elevations & Cross Sections.
  • Access & Share “LIVE” Point Cloud Data.
  • Data Capture – HD Laser Scanning & UAV.
  • 2D & 3D AutoCAD DWG’s & PDF formats.
  • 3D Models (Revit Architectural Models).

Survey Data can be delivered in a variety of industry standard 2D & 3D formats, including 3D Revit Models with 3D Point Cloud Data available to access remotely through our “Shared” Point Cloud Platform providing instant access & rapid dimensional interrogation.

Measured Building Surveys are related to the Ordnance Survey National Grid Reference System (OSGB36) & Ordnance Datum (AOD) & delivered in accordance with the RICS Specification: Measured Surveys of Land, Buildings & Utilities – 3rd Edition.

Drift Bridge House
Measured Building Surveys (MBS)

Measured Building Surveys

Measured Building Survey deliverables/outputs aid in the Planning & Design process for Architectural & Construction/Engineering purposes.

Our Team of experienced Geospatial Surveyors integrated with the latest cutting-edge technology & proven processes allow us to deliver an efficient & cost-effective solution to all your Measured Building Survey requirements.

Sample Measured Building Survey (MBS) Specification

Features to be shown would include but not limited to; structural detail/features; walls (structural & non-structural), beams, columns, stairs, door & window openings & detail, floor & ceiling heights, door heights, window head & sill heights.

  • Photographic Documentation of Structures.
  • Access & Share “LIVE” Point Cloud Data.
  • Data Capture – HD Laser Scanning & UAV.
  • 2D & 3D AutoCAD DWG’s & PDF formats.
  • 3D Models (Revit Architectural Models).

Measured Building Surveys are related to the Ordnance Survey National Grid Reference System (OSGB36) & Ordnance Datum (AOD) & delivered in accordance with the RICS Specification: Measured Surveys of Land, Buildings & Utilities – 3rd Edition.

SurveyWorx can deliver various levels of detail, accurately Surveyed, Edited, & Presented to suit your needs, whether they relate to the Planning, Renovation, Restoration, or Refurbishment of an existing Building/Structure.

Get in touch today to discuss your Project & let us deliver an efficient & cost-effective solution to your Measured Survey requirements.

Survey Methodology & Delivery

Using an extensive range of HD Laser Scanning Technology, Robotic Total Stations, Hand-Held Tablets & “Robust Survey Methods” to efficiently capture highly accurate data, we have the expertise & resources to provide a solution to all your Measured Survey requirements.

Survey Data is Post-Processed in-house through the use of dedicated Survey Mapping Software & rigorous QA/QC procedures to ensure we deliver consistent & reliable results.

Survey Data can be delivered in 2D & 3D formats, including 3D Models (Revit, Wireframe, Solid, Surface, Architectural Models).

Our experience combined with our commitment to new technology & innovations ensures we can efficiently & cost effectively deliver your Project to the highest possible quality standards.
